NAXPRO-TRUSS HD 42 TRUSS CIRCLE 8 M HORIZONTAL | HD 42 Circles

Naxpro-Truss HD 42 Truss Circle 8 m Horizontal

Truss domes, truss circles and stages with round roofs have one thing in common: constructions with bent elements are always an optical highlight. Also as illuminated banner frames, truss circles attract the attention of visitors and highlight your advertisements.

By default truss circles with a diameter from 2 up to 10 m are offered. By request we will also manufacture custom sizes with a diameter above 10 m. Our truss circles are available in all RAL-colours.

Technical data:
Outside diameter: 800 cm
Inside diameter: 720 cm
Seperated in 8 segments each 45°
Edge dimension: 400 mm
Tube: 50 x 3 mm
Alloy: EN AW 6082 T6
Incl. connector set
Weight: 92,94 kg
