NAXPRO-TRUSS FD 22 TRUSS CIRCLE 7 M VERTICAL | FD 22 Circles

Naxpro-Truss FD 22 Truss Circle 7 m Vertical

Truss domes, truss circles and stages with round roofs have one thing in common: constructions with bent elements are always an optical highlight. Also as illuminated banner frames, truss circles attract the attention of visitors and highlight your advertisements.

By default truss circles with a diameter from 2 up to 10 m are offered. By request we will also manufacture custom sizes with a diameter above 10 m. Our truss circles are available in all RAL-colours.

Technical data:
Outside diameter: 700 cm
Inside diameter: 693 cm
Seperated in 8 segments each 45º
Edge dimension: 35 mm
Tube: 35 x 2 mm
Alloy: EN AW 6060 T66
Incl. connector set
Weight: 33,00 kg


Downloads: Data sheet
